The CGR100 product is a powerful 100M router, suitable for small and medium-sized enterprises or small workstation deployment environments. The device supports IP/MAC binding, MAC address filtering, ACL, NAT, and interface access control functions, and has strong security management capabilities.

The CGR100 product has a high coverage and high-speed WIFI access capability, can simultaneously cover the 2.4G and 5G frequency bands, and supports the 802.11AC fifth generation WIFI protocol and is compatible with all previous WIFI protocols. 802.11AC protocol can theoretically reach 1Gbps transmission rate, enabling WIFI users to experience gigabit fast transmission experience.

The device also supports IPSec VPN, GRE VPN, L2TP VPN and other tunnel protocols, which can meet the security needs of customers for data encryption.

Hardware Specifications

CPU Model/Cores: MT7628/Monokaryon
FLASH: 16M
RAM: 64M
WAN(Ethernet): 1 * FE Electric，10/100 Mbit/s adaptive
LAN(Ethernet): 2 * FE Electric，10/100 Mbit/s adaptive
2G: GSM:900/1800MHz
4G: LTE TDD:B34/B38/B39/B40/B41
LTE FDD:B1/B3/B5/B8
Band: 2.4 GHz/5.8GHz
Wireless standard: IEEE 802.11 a/n/ac
Wireless power: 20 dBm
Wireless reception sensitivity: -92 dBm
Wireless encryption: WPA-PSK,WPA2-PSK,WPA-PSK/WPA2-PSK
4G antenna: External omnidirectional non-detachable 5dBi * 2
WIFI antenna: 2.4GHz/5.8GHz external omnidirectional 5dBi * 2
Power adapter specifications: Input voltage/frequency：DC 100-240V/50-60HZ; Output voltage/current：12V/1A
Operating environment: -10~55℃
Overall size: 265*160*36mm

Software parameters

Basic characteristics: IPv4、TCP/UDP、ARP、ICMP、DHCP
4G: FDD LTE、TDD LTE、WCDMA、GPRS、GSM
Access security: IP/MAC binding, MAC address filtering
Access control: ACL, NAT, Interface Access Control
VPN: IPSec VPN、GRE VPN、L2TP VPN
Web Administration: http、https
Remote management: TR069
Firmware management: Web local upgrade, Platform remote upgrade

High-speed wireless network, leading technology

1)Support 4G mobile network
2)Support WIFI5 technology to establish a faster wireless LAN

Access level control, ultimate security

1)Support IP/MAC binding, MAC address filtering, and access level security control capability
2)Support ACL and NAT functions to ensure safe forwarding
3)Support interface access control function

Rich interfaces and flexible networking

1)Supports LTE FDD and LTE TDD, and is compatible with WCDMA/GPRS/GSM
2)Support Ethernet interface and 100M level access
3)Support WIFI access and more flexible networking

Secure forwarding and powerful encryption function

1)Support IPSec VPN, GRE VPN and L2TP VPN tunnel technologies
2)2)IPSec VPN supports RSA international standard authentication encryption and decryption algorithm system
3)IPSec VPN supports China's national security authentication algorithm system

Unified management and simple maintenance

1)Support the TR069 protocol, which can be centrally managed by the management platform
2)2)Support http and https protocols, make the web configuration interface more friendly and easier to operate
